Features:
Slim and Low profile (31mm)
Fanless design,350W convection
Withstand 300VAC surge input for 5 seconds
Built-in active PFC function
150% peak load capability(100ms)
-30~+70℃working temperature
Protections: Short circuit / Overload / Over voltage / Over temperature
DC OK active signal and redundant function(option)
Operating altitude up to 5000 meter
Over voltage category Ⅲ
LED indicator for power on
3 years warranty

General Specification:
AC input voltage range:90~264VAC 127~370VDC
AC inrush current (Typ.):Cold start :30A/115VAC 60A/230VAC
Overload protection:110~140% rated output power Protection type : Hiccup mode, recovers automatically after fault condition is removed
Over voltage protection:12V:13.2~15.6V,15V:16.5~19.5V, 24V:26.4~31.2V, 36V:39.6~46.8V, 48V:52.8~62.4V Protection type :Shut down O/P voltage,re-power on to recover
Setup, rise, hold up time:2000ms,80ms/230VAC/115VAC at full load; 10ms/115VAC，230VAC
Withstand voltage:I/P-O/P:3.75KVAC I/P-FG:2.0KVAC O/P-FG:1.25KVAC
Working temperature:-30~+70℃(Refer to “Derating Curve)
Safety standards:UL60950-1,TUV EN60950-1,EN60335-1, CCC GB4943, EAC TP TC 004,BSMI CNS14336-1 approved, Design refer to EN61558-1,-2-16
EMC standards:Compliance to EN55032,GB9254,Class B, EN55014,EN61000-3-2,-3,EAC TP TC 020,BSMI CNS13438; Compliance to EN61000-4-2,3,4,5,6,8,11;EN61000-6-2 (EN50082-2), heavy industry level ,criterial A,EAC TP TC 020
Dimension (LxWxH):220×62×31mm
