Hardware Supporting Specifications:
Motherboard:MATX(245*245mm) /ITX(170*170mm) ( I/O frame crossing ≤6mm)
Power Supply:ATX (length limit 140-170mm), SFX, SFX-L (Pay attention to the conflict between graphics card length and power supply)
Hard Drives:The rear panel can support 3.5"*1 HDD (ITX motherboard) or 2.5"*1-2 SSD or bottom side mounted 3.5"*3 HDD or 2.5"*6 SSD or side mounted 3.5"*1+2.5"*1 hard drives or bottom horizontal mounted 3.5"* 1
Graphics Card: 3-slot GPU with a maximum size 340*142*78mm (including rear panel)
(Notice: Supports most 4090 and other 40 series GPU. When the power length is ≤140mm, the graphics card is limited to 340mm in length. When the power length is>140mm but ≤170mm, the GPU length limit is 270mm and thickness ≤55mm with a fan or with a horizontal HDD )
CPU Cooling and Water Cooling Pump: High tower height limit 135mm(Notice: The fan near the memory of the twin towers may protrude due to the height of the memory, please be careful not to exceed the height of the middle 140 fan) Internal cooling pump height ≤ 70mm
Front interface: 10G/Type-C * 1
Fans:
Top fan 12025*2
Rear window fan 9025*1
Bottom fan 12025*2
Side support 2*120-25 fans
(CPU radiator height is within 105mm without water cooling)
Water Cooling:
240/120 integrated water cooling*1 (length≤ 283mm, pump height≤70mm) * water cooling length limit within 278mm (rear window can fit 90-25 fans) * water cooling length limit 285mm (rear window can fit 90-15 fans)
Attention should be paid to placing the water-cooled tube on the side of thepower supply(SFX/SFXL) during installation

Case Parameters:
Case size: 371*168*286mm(Without handle and foot rest)
Case Capacity: 17.8L
Material: AL-MG high strength magnesium aluminum alloy
Case Color: Anodized silver
Frame Thickness: 3.0mm
Other components thickness: 1.5mm
2 Side panel thickness: 2.0mm
Net weight: 3.2KG
Gross weight: 4.3KG(including package)
Package Size: 450*240*410mm

Package Including:
B2Pro Case *1
Handle*2
9cm fan dust net * 1
Accessory Box * 1
PCIE blocking plate * 3
Rubber pads*2
