Features:
Its an advance pressure transducer than traditional mechanical pressure transducer.
±2%FS small output error, including nonlinear, hysteresis error and repeatability, full temperature range.
Light weight and small size, convenient to install and operate.
It has complete surge power input protection function.
Works for oil, fuel, for heavy-duty vehicles, gas, water, air pressure, can be used in oil tank, gas tank, for heavy-duty vehicles tank etc.
Specifications:
Material: Stainless steel
Power input: DC 5V
Pressure: 30 psi, 100 psi, 150 psi, 200 psi, 300 psi, 500 psi (Optional)
ThreadType: 1/8" NPT
Parameters
Measuring range: -14.5-30psi / 5-300psi gauge
pressure
Accuracy: ±1.0%FS
Output signal: 0.5-4.5V, 0-5V, 1-5V
Supply power input: 5VDC, 12VDC, 3.3VDC
Operating temperature: -40-105
Compensation temperature: -20-80
Operating current: 3mA
Temperature drift (zero&sensitivity ±0.03%FS/
Long-term stability: ±0.2%FS/year
Response time: 3ms
Overload pressure: 150%FS
Burst pressure: 300%FS
Cycle life: 500,000 times
Sensor core: Al2O3-96% ceramic sensor
Pressure medium: Non-corrosive liquid or gas
Pressure connection: 1/8"NPT, Other pressure connection is on request
Housing material: 304 Stainless Steel
Protection class: IP65
Explosion-proof class: ExiaCT6
Weight: 0.080kg
