General Specifications
SKU: 6PRO600SE-8
Nominal Diameter: 6.5" / 165mm
Nominal Impedance: 8 Ohms
RMS Power Handling: 300W
MAX Power Handling: 600W
Sensitivity (1w/1m): 96dB
Frequency Response: 250Hz – 12.5kHz
Recommended HI Pass Crossover: 320Hz
Sold As: Single unit
Grill Included: No

Features

Demodulating Ring: Copper
Cone Shape: Curvilinear
Speaker Terminals: Spade
Motor

Voice Coil Diameter: 2" / 50.6mm
Voice Coil Former Material: Fiberglass
Winding Material: CCAW
Cone Material: Paper
Dust Cap Material: Paper
Surround Material: Cloth
Basket Material: Steel (Black finish)
Magnet Material: Ferrite
Magnet Weight: 45 Oz
Displacement Volume: 1.26L / 0.044ft³

Thiele & Small Parameters

Equivalent Volume (Vas): 0.48L / 0.0171ft³
Excursion (Xmax, one way): 1.2mm
Free Air Resonance (Fs): 490Hz
Mechanical Factor (Qms): 8.49
Electrical Factor (Qes): 2.4
Total Factor (Qts): 1.87
Mechanical Mass (Mms): 18.165g
Mechanical Compliance (Cms): 0.018mm/N
BL Factor: 6.457
Voice Coil Inductance (Le): 0.1317mH
Cone Area (Sd): 138.93cm²
DC Resistance (Re): 5.2 Ohms

Measurements

Overall Diameter: 6.54" / 166.2mm
Overall Depth: 2.83" / 71.8mm
Front Mount Baffle Cutout: 5.68" / 144.3mm
Mounting Depth: 2.6" / 66mm
Motor Diameter: 5.5" / 140mm
