Part Number: 725-3001, 925-3001, 035634, 20626200

Specification:
Terminals: 3
Voltage: 12V
Work Current: 50A
Inrush Current: 60A
(2) 5/16-18 Terminals
(1) 10-32 Terminal
Mounting Type: 90 Degree

Application:
Compatible with MTD Pro the following models:
1748F 55AF3DAM195
1848F 55AF3C5M195
1852H 55AF3C5T195
MMZ-1848 53AB555M195

Compatible with International Harvester the following models:
Cadet 75 Riding Mower-Built 1972-1981
Cadet 85 & 86 Riding Mower-Built 1975 & Since 32" Deck
Cadet 85 Special & 87 Riding Riding Mower-Built 1975 & Since 28" Deck
Cub 154 Lo-Boy
Cub 184 Lo-Boy
Cub 185 Lo-Boy

Compatible with Z-Force the following models:
42
44
48
54
60
3648
3654
M48-KW Tank
M48-KWS Tank
M54-KW Tank
M60-KW Tank
M72-KW Tank

Compatible with Craftsman Zero Turn Rider Mower: ZTL7500

Compatible with White Outdoor the following models:
Z-16 (1999) 53BA1A3G190 (1999)
Z-16 53AC225G190
Z-165 53CA1A3G190
Z-180 53AC235M190
Z-200 (1999) 53BA1A6M190
Z-200 53AC275K190
Z-220 53BA1A7K190
ZT-1850
ZT-1850 (2001) 53AA1A5L190 (2001)
ZT-2150
ZT-2150 (2001) 53CA1A6M190 (2001)
ZT-2250
ZT-2250 (2001) 53CA1A7K190 (2001)
ZTL7500 17AL3AGV099 (247.25003) (2012) 17AL3AGV099 (2012)

Compatible with Cub Cadet the following models:
1000 (2050540U / 2050550U) 2050540U 2050550U
1050 S/N 756,300-799,999 (149-605-100) 149-605-100
108 (2050043U / 2050209U / 2050210U) 2050043U 2050209U 2050210U
109 (2050044U / 2050211U / 2050213U) 2050044U 2050211U 2050213U
1100 (2050590U) 2050590U
111 0350025U
1200 (2050056U / 2050570U / 2050580U) 2050056U 2050570U 2050580U
1204 S/N 756,300-799,999 (147-610-100 / 148-610-100) 147-610-100 148-610-100
1210 S/N 756,300-799,999 (147-620-100 / 148-620-100 / 149-620-100) 147-620-100 148-620-100 149-620-100
1210, 1282, 680 1210 756,299 & Prior 1282 142-680-100 142-680-399 143-680-100 143-680-399 144-680-100 144-680-399 145-680-100 145-680-399 146-680-100 2050587U 2050603U 680
1211 S/N 756,300-799,999 (147-630-100 / 148-630-100 / 149-630-100) 147-630-100 148-630-100 149-630-100
1250 (2050059 / 2050610U / 2050630) 2050059 2050610U 2050630
128 (2050045U / 2050217U / 2050218U) 2050045U 2050217U 2050218U
129 (2050046U / 2050220U / 2050221U / 2050222U / 2050223U) 2050046U 2050220U 2050221U 2050222U 2050223U
1440 S/N 821,060-880,000 (142-633-100 / 143-633-100 / 144-633-100 / 145-633-100) 142-633-100 143-633-100 144-633-100 145-633-100
1440 S/N 880,001-899,000 (146-633-100 / 14A-633-100 / 14A-663-100) 146-633-100 14A-633-100 14A-663-100
1450 (2050065U / 2050660U) 2050065U 2050660U
149 (2050047U / 2050205U / 2050206U / 2050224U) 2050047U 2050205U 2050206U 2050224U
1604, 1606, 580, 582 142-580-100 142-582-100 142-582-399 143-580-100 143-582-100 143-582-399 144-580-100 144-582-100 144-582-399 145-580-100 145-582-100 145-582-399 146-580-100 146-582-100 1604 1606 205-0582 2050582U 2050583U 2050596U 2050598U 2050599U 58
1650 (2050067U / 2050070U / 2050670U) 2050067U 2050070U 2050670U
169 (2050048U) 2050048U
1710, 682 142-682-100 142-682-399 143-682-100 143-682-399 144-682-100 144-682-399 145-682-100 145-682-399 1710 205-0600 2050584U 2050592U 2050593U 2050600U 682
1711, 1712, 782, 784 142-782-100 142-784-100 142-784-399 143-782-100 143-784-100 143-784-399 144-782-100 144-784-100 145-782-100 145-784-100 1711 1712 2050585U 2050594U 2050601U 782 784 784142 784143
1806 S/N 756,300-799,999 (147-640-100 / 148-640-100 / 149-640-100) 147-640-100 148-640-100 149-640-100
1810 S/N 756,300-799,999 (146-682-100 / 147-650-100 / 148-650-100 / 149-650-100) 146-682-100 147-650-100 148-650-100 149-650-100
1811 & 1812 S/N 756,300-799,999 146-782-100 146-784-100 147-660-100 147-670-100 147-720-100 148-660-100 148-670-100 149-660-100 149-670-100 1811 S/N 756,300-799,999 1812 S/N 756,300-799,999
182 0350027U 0350030U 132-182-100 132-182-399 133-182-100 133-182-399 134-182-100 134-182-399
1861 S/N 821,060-836,000 (140-671-100 / 142-663-100) 140-671-100 142-663-100
1862 S/N 821,060-836,000 (142-683-100) 142-683-100
1872 & 2072 S/N 756,300-799,999 147-730-100 148-720-100 148-730-100 149-720-100 149-730-100 1872 S/N 756,300-799,999 2072 S/N 756,300-799,999
1912 145-982-100 145-982-399 146-982-100 146-982-399
1914 145-986-100 145-986-399 146-986-100 146-986-399
2082 S/N 821,060-836,000 142-732-100
2160 Tractor S/N 326,006-389,000 136-266-100 13A-266-100
2164 Tractor 13A-264G100
2165 Tractor S/N 239,001-326,005 134-268-100 135-268-100
2165 Tractor S/N 326,006 & Up 136-268-100 13A-268-100
282 0350026U 0350031U 132-282-100 132-282-399 133-282-100 133-282-399 134-282-100 134-282-399
364 (2001) 53AA1A5L100 (2001)
364 53AA1A5L100
382 Gear & 383 Hydro 0350028U 0350029U 0350032U 0350033U 0350036U 0350037U 132-382-100 132-382-399 132-383-100 133-382-100 133-382-399 133-383-100 134-382-100 134-382-399 134-383-100 382 Gear 383 Hydro
482 142-482-100 142-482-399 143-482-100 143-482-399 144-482-100 144-482-399 2050581U 2050597U
76 0350001U 0350009 0350010
80 0350002U 0350021U
800 (2050050U / 2050510U / 2050520U) 2050050U 2050510U 2050520U
81 0350003U
86 (2050042U / 2050207U / 2050208U) 2050042U 2050207U 2050208U
982 142-982-100 142-982-399 143-982-100 143-982-399 144-982-100 144-982-399 2050586U 2050595U 2050602U 2050604U 2050605U
984 142-984-100 142-984-399 143-984-100 143-984-399 144-984-100 144-984-399 2050589U
986 142-986-100 142-986-399 143-986-100 143-986-399 144-986-100 144-986-399 2050588U
GT2521-48 Tractor 13A-278M710
LT2180 Tractor 13A-254G710 13A-254G712
Z42 (1999) 53BA1B2G100 (HM 1999)
Z42 53AC305G100
