Contact Resistance: 100MΩ Max (Initial) (b) 200mΩ (After Final Test)
Insulation Resistance: 100MΩ Min, 250VDC
Operating Temperature Range: -25 C to 80 C
Solderability: 230 ±5 C 3± sec 75%
Electrical Life: 200mΩ Max, 20000 Steps
Electrical Rating: 13A-120V AC, 10(3)A-250V AC
Temperature(c): 105°C
POl/Thr: 1/2 or M
PP/Circuit: --/A
Durability: 10000 Cycles
SPCOA: 22-14AWG UL1015
Quantity: 1 piece
Note:
Please allow 1-2mm error due to manual measurement
Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you!
