5-PIN SPDT Automotive Relay 40/30A AMP 12V DC 5 Pack Waterproof Starter Relay Kit with Heavy-Duty 12 AWG Tinned Copper Wires, Automotive Cars and Trucks in Saudi Arabia 5-PIN SPDT Automotive Relay 40/30A AMP 12V DC 5 Pack Waterproof Starter Relay Kit with Heavy-Duty 12 AWG Tinned Copper Wires, Automotive Cars and Trucks in Saudi Arabia 5-PIN SPDT Automotive Relay 40/30A AMP 12V DC 5 Pack Waterproof Starter Relay Kit with Heavy-Duty 12 AWG Tinned Copper Wires, Automotive Cars and Trucks in Saudi Arabia 5-PIN SPDT Automotive Relay 40/30A AMP 12V DC 5 Pack Waterproof Starter Relay Kit with Heavy-Duty 12 AWG Tinned Copper Wires, Automotive Cars and Trucks in Saudi Arabia

5-PIN SPDT Automotive Relay 40/30A AMP 12V DC 5 Pack Waterproof Starter Relay Kit with Heavy-Duty 12 AWG Tinned Copper Wires, Automotive Cars and Trucks

SAR 84
SAR 120
– 1 +

Special Features

  • The relay adopts pure copper core cable, silver alloy contact, strong conductivity, better stability, and the relay kit adopts high-grade flame retardant materials to ensure safe use and long service life.
  • Nominal Coil Voltage: 12 V DC; Coil Power: 1.8 W; Coil Resistance: 80 Ω; Must Operate Voltage: 6~8 V DC; Must Release Voltage: 0.6~3.6 V DC; Maximum Applied Voltage: 15.6 V DC
  • Be careful when inserting the relay into the socket. If you force it, you will bend the female connectors,Primary leads use 12 a.w.g tinned copper wire. Coil leads use 16 a.w.g
  • These DC waterproof relays and wiring harnesses feature quick-install design for effortless replacement of worn-out relays. This 12V relay engineered with industrial-grade composite housing and high-purity copper coils to ensure optimal conductivity and voltage stability. Our automotive relays are made of longer 12+16 gauge tinned copper wire, which is more resistant to corrosion and oxidation than bare copper wire.
  • No reason to return within 30 days, 1-year warranty service; If you are not satisfied with this product, please contact us for an exchange or refund. We hope you will enjoy excellent service.

Description

Nominal Coil Voltage: 12 V DC
Coil Power: 1.8 W
Coil Resistance: 80 Ω
Must Operate Voltage: 6~8 V DC
Must Release Voltage: 0.6~3.6 V DC
Maximum Applied Voltage: 15.6 V DC
Contact Ratings: NO 40A 14V DC
Contact Resistance: 100mMAX (at6VDC 1A)
Max Switching Current: 40A
Max Switching Power: 560 W
Life Expectancy Electrical: 100,000 Operations (at30 Operations/minute)
Life Expectancy Machanical: 10,000,000 Operations
Temperature Range: -30 ~ +80 degrees Celsius
Vibration Resistance: 10~55Hz, 1.5mm
Shock Resistance: Operations Extremes: 10g. Damage Limits: 100g
Hunidity: 40% ~ 85%
Insulation Resistance: 100mΩ Min at500VDC
Dielectric Strength Between Open Contacts: 500VAC (for one minute/sec)
Between Contactw and coil: 750AC (for one minute/sec)
Operate Tice: 7ms
Release Tice: 5ms
Package Content: 5 x 12VDC waterproof relay kit
