*Description:
This is a combination of a 370 turbine motor and a mounting bracket, the bracket as an additional support for your motors or as an alternative mounting option.
You can change the wiring of the motor positive or negative change the direction of rotation of the motor, using full metal gear, low noise, with self-locking function.

*Specification of motor:
Rated voltage: 12V DC;
Gear Ratio :5300;
Speed: 0.6RPM;
Torque :≤30kg.cm;
Shaft: D-shaft;
Shaft Diameter:6mm;
Female thread diameter of shaft:3mm*12mm;
Total Shaft Length: 14mm;
*Specification of bracket:
Length: 38mm;
Width: 46mm;
Height: 30mm;
Thickness：3mm;
Material: high carbon steel;
Standard or Nonstandard: Standard.

*Package:
1 x 370WG DC Worm Gear Motor, 1 x bracket, 4x screws.

*Application:
Label machines, remote control curtains, automatic voltage regulators, barbecue grills, ovens, washers, waste disposal machines, household appliances, coin machines, paper currency recognizers, automatic actuators, coffee machines, towel machines, printing machines and Stage lighting.
