12Pcs 12V One Channel Relay Module OPTO Isolation High Low Level Trigger Relay Switch for Raspberry Pi Arduino

Sorry, this product is not available
All electronics ship with US style plugs. You may need a voltage converter or a plug adapter.

Special Features

  • Maximum Load: AC: 250V/10A; DC: 30V/10A. Trigger Current: 10 Amps
  • Reliable Relay Switch: These relay modules feature high-quality relays and open interfaces, ensuring stable and dependable performance in diverse conditions.
  • Optocoupler Isolation: Equipped with SMD optocoupler isolation, these Relay Modules provide strong driving capabilities while safeguarding I/O ports from potential relay switch current damage.
  • Flexible Trigger Control: Effortlessly configure trigger modes as high or low using jumpers, allowing adaptability for various control scenarios.
  • User-Friendly Integration: Relay Modules are designed for user convenience, ensuring easy installation via screw terminals and fixed bolt holes. They seamlessly integrate with various microcontrollers, including Arduino, AVR, PIC, ARM, DSP, making them versatile for a wide array of projects, from microcontroller development to appliance control.

Description

ENLOZURE One Channel 12V Relay Module

Specifications:
Package Included: 12 Pieces of 12V 1 Channel Relay Module
Working Voltage: 12V
Number of Channels: 1
Normally Open Compatible Load: 10A 250VAC / 10A 30VDC
Power Indicator: Green
Relay Status Indicator: Red
Module Size: 50*25*18 mm / 1.968*0.984*0.709 inch (L*W*H)

Input Interface:
DC+: Power Positive (According to the relay voltage range)
DC-: Power Negative
IN: Signal Trigger Input (High or Low Level Signal Selection via Jumper)

Relay Output:
NO: Relay Normally Open
COM: Relay Common Pin
NC: Relay Normally Closed

High or Low-Level Trigger Selection:
High-Level Trigger:
When the "IN" input receives a High-Level Signal, the "NO" connects with "COM"
When the "IN" input receives a Low-Level Signal, the "NC" connects with "COM"
Low-Level Trigger:
When the "IN" input receives a Low-Level Signal, the "NO" connects with "COM"
When the "IN" input receives a High-Level Signal, the "NC" connects with "COM"
High or Low-Level Trigger Selection:
To select High-Level Trigger, connect the jumper to "H"
To select Low-Level Trigger, connect the jumper to "L"
