Nextion Intelligent 4.3 inch HMI Display NX4827P043-011C Capacitive Touch Screen 5V TFT LCD 480x272 for Arduino ESP32 (NX4827P043-011C) in Saudi Arabia Nextion Intelligent 4.3 inch HMI Display NX4827P043-011C Capacitive Touch Screen 5V TFT LCD 480x272 for Arduino ESP32 (NX4827P043-011C) in Saudi Arabia Nextion Intelligent 4.3 inch HMI Display NX4827P043-011C Capacitive Touch Screen 5V TFT LCD 480x272 for Arduino ESP32 (NX4827P043-011C) in Saudi Arabia Nextion Intelligent 4.3 inch HMI Display NX4827P043-011C Capacitive Touch Screen 5V TFT LCD 480x272 for Arduino ESP32 (NX4827P043-011C) in Saudi Arabia Nextion Intelligent 4.3 inch HMI Display NX4827P043-011C Capacitive Touch Screen 5V TFT LCD 480x272 for Arduino ESP32 (NX4827P043-011C) in Saudi Arabia Nextion Intelligent 4.3 inch HMI Display NX4827P043-011C Capacitive Touch Screen 5V TFT LCD 480x272 for Arduino ESP32 (NX4827P043-011C) in Saudi Arabia

Nextion Intelligent 4.3 inch HMI Display 5V Capacitive Touch Screen 480x272 TFT LCD w/Enclosure Case for Arduino (NX4827P043-011C-Y) NX4827P043-011C-Y

SAR 365
StyleNX4827P043-011C-Y
All electronics ship with US style plugs. You may need a voltage converter or a plug adapter.
– 1 +

Special Features

  • -Compared with Nextion Basic & Nextion Enhanced, Nextion Intelligent display has more powerful hardware in terms of MCU, Flash storage and SRAM. Audio, video and animation play functions enrich your project HMI interaction.
  • -Nextion intelligent 4.3 display is a 5V device, but many development boards are 3.3V. It won't make the display power up.
  • -To ensure Nextion 4.3 intelligent display work as expected, it's recommended to supply power via power adapter, not usb to ttl or boards.
  • -Battery socket, NOT supply power for nextion display, is only used to keep the Real Time Clock running when no power to nextion screen.
  • -Uploading TFT file via sd card is faster than the usb to ttl, but pls ensure card: FAT32 format, only one tft file(no folder), and no more than 32GB.

Description

Feature
4.3" LCD-TFT HMI display module
480 x 272 screen resolution
RGB 65K true-to-life colours
Capacitive touch panel
300 nit Brightness
Onboard 200MHz MCU
512 KB of SRAM
128 MB of Flash memory
1024 Byte EEPROM
XH2.54 4 Pins (+5V, TX, RX, GND) TTL serial interface
1.25T-2-2A Audio port for external speaker connection
16Ω 0.5W power for speaker (speaker NOT included) 8 Digital extended GPIO
(IO0-IO7 support input, output and component binding event, IO6-IO7 support PWM)

Package Included:
1 x Nextion NX4827P043-011C
1 x micro USB to 2pin male board
1 x 4pin 2.54mm to female cable
