Name: LattePanda 7"eDP Touch Display Alpha & Delta
Brand: LattePanda
Availability: InStock

Special Features

【Excellent Visual Effect】This display adopts IPS screen technology, support 178-degree visual Angle, 1024 x 600 high resolution and high color saturation, achieve excellent picture.
【Designed For HMI and Portable Projects】We have made many product design optimizations for HMI and portable project requirements. For example, HMI scenarios are often complex and dusty, but this display uses a fully fit design to perfectly prevent dust from entering the screen, and also effectively reduces the reflection of light. In order to make the screen easy to be installed, the screen edge comes with the special double-sided adhesive tape, which can be easily and firmly fixed.
【Best Compatibility】Unlike other normal HDMI screens, this display uses eDP interface, and has the best compatibility with LattePanda alpha & delta (not compatible with LattePanda V1.0). It allows you to set screen power, brightness, contrast and other parameters directly in the OS or APIs.

Description

Official Website https://www.lattepanda.com/
Note:It's NOT compatible with LattePanda V1.0 Edition.

Features
1024 x 600 high resolution
Capacitive screen

Specification
1024 x 600 high resolution
Transmittance：85%
Surface Hardness： 6H
Response Time: ≤16ms
Tapping Durability: 200,000,000 times
Supports LattePanda Alpha & Delta
Connector: 10cm FPC Extension Cable
Dimensions: 180*110*5 mm / 7.1*4.3*0.2 inches

Shipping list
7”eDP Touch Display x1
30pin eDP cable x1
