This Battery Monitor is designed to monitor performance most kind of battery systems with capacities of up to 999 Amp hours.
Read your battery bank like a fuel gauge.
Battery Status at a glance.
Combines many functions in one, these information leads to more efficient use of the battery, which can enhance battery life and reduce the risk of failure.
State of Charge (%),The remaining battery capacity (AH).
Charge and discharge current (A), Voltage (V).
Charging status indicator, looks like a smartphone.
It is suitable for mobile and portable equipments, e-bike, balance cars, cleaning machines, instruments, ups and so on.
This item is suitable for lithium batteries, lithium iron phosphate batteries,
lead-acid batteries and nickel-metal hydride batteries which working voltage is from 8V to 100V.
Have memory function.
Doesn't require isolated power, self-powered 8-80V.
It is very easy to install.

Specifications
Working voltag: 8.0-100.0 V
Current range: -350~+350 amps
Capacity range: 0-999 ampere-hour
Working consumption: 10.0-12.0 mA
Standby consumption: 0.5-0.6 mA
Sleep consumption: 50-60 uA
Voltage accuracy: ± 1.0 %
Current accuracy: ± 1.0 %
Capacity accuracy: ± 1.0 %
Preset capacity value: 0.1-999 Ah
Temperature range: 0-35℃
Weight: 400g
Size: ø59mm*20 mm
Mounting hole: diameter 54mm

The auction includes
1 x Battery monitor
1 x Current sampler
1 x 2 meters long cable
1 x English operation manual
