Valve
Head link size:
Plastic head: 1/4
Stainless steel head: 1/8
Actuator size :50mm
==========
Hign-concerned Chemical : None
NC or NO : NORMALLY CLOSED
Actuator Mode : With Manual And Instruction
Structure : ANGLE
Port Size : 1/2" 3/4" 1"
Media : Base
Material : Stainless Steel
Temperature of Media : High Temperature
Power : Pneumatic
Standard or Nonstandard : Standard
Pressure : High Pressure
Model Number : Angle seat valve
Origin : Mainland China
For : Air gas oil water
Control pressure range : 0.3-0.8MPa
Manufacturing material : SS304
Temperature resistance(Plastic head) : 145
Temperature resistance(Steel head) : 180
Max pressure : 16Bar
Valve core seal : PTFE
Valve Rod : PTFE
