Planetary Gearbox 1:47 1:55 1:72 1:77 Dual Axis 56mmSpeed up or Speed
Reduce Double Shaft also Used as Speed Reducer PLZ56
Dual Axis Planetary Gearbox*1pc
This planetary gearbox can improve the output speed in turn it can also be used as one speed reducer from the other side.
About model:
1 to 47 Speed up--ratio 1:47 and it is speed-up gearbox.(input axis is 12mm with keyway output
axis is 12mm with keyway )
47 to 1 Reducer--ratio 47:1 and it is speed reducer.(input axis is 12mm with keyway output
axis is 12mm with keyway )
This link is for gear ratio47/55/72/77
We have ratio from 3.6 to 77. if need other gear ratio order other link or contact us.
Stage1 ratio:3.6/4/4.25/5.3
Stage2 ratio: 13/15/18/28
Stage3 ratio: 47/55/72/77
Installation dimension:
Note: One end shaft diameter is 10mm for ratio 5.3 and 28. Dual axis both 12mm for other ratio.
