This product is a single hollow linear shaft designed for precision linear motion systems. Its core advantage lies in the hollow structure, which significantly reduces the mass of the moving assembly compared to a solid shaft of equivalent diameter, thereby reducing inertia and enabling higher acceleration and deceleration in dynamic applications. The shaft is manufactured from carbon steel, which is through-hardened to provide a tough core, and finished with a hard chrome plating that delivers a smooth, wear-resistant, and corrosion-resistant surface.
Available in a range of industry-standard outer diameters with corresponding inner bores, it allows for internal routing of cables or tubes, contributing to a cleaner machine design. The specified standard lengths cater to common design needs. This component is ideal for integration into or as a replacement part for equipment where precision, reduced moving mass, and durability are critical, such as in linear guides, gantry systems, and high-performance automation stages.
Product Type:\u200b Hardened & Chrome Plated Hollow Linear Shaft
Materialu200b Carbon Steel (Hardened)
Structure:\u200b Hollow Round Tube
Outer Diameter (OD) & Inner Diameter ID Options:
OD 10 mm: ID 4 mm
OD 12 mm: ID 6 mm or 6.7 mm
OD 14 mm: ID 9 mm
OD 16 mm: ID 8 mm or 10 mm
OD 20 mm: ID 12 mm or 14 mm
Length Options (mm):\u200b 50, 100, 300, 600, 800, 1000
Surface Treatment:\u200b Hardening & Chrome Plating
Quantityu200b 1 piece
Key Features:\u200b Lightweight, High Rigidity, Wear and Corrosion , Internal Bore for Cable Routing
Primary Application:\u200b Guide shaft for linear motion systems in automation, CNC, and precision machinery.
