This product is a pair of chrome-plated, hardened linear shafts designed for integration into precision linear motion assemblies. The chrome plating over a hardened steel substrate creates a durable, smooth, and corrosion-resistant surface essential for long service life and consistent performance when used with linear bearings (e.g., ball bushings). A key feature is the pre-drilled and tapped holes at both ends of each shaft. This design allows for straightforward and secure mounting to frames, brackets, or between end supports using standard metric screws, eliminating the need for additional shaft collars or complex fixtures in many applications.
The shafts are supplied as a matched set of two, which is typical for constructing a stable parallel guide system. Available in standard diameters and customizable lengths, they offer flexibility for various mechanical designs. These components are commonly employed in building or repairing the motion systems of DIY CNC routers, 3D printers, laser engravers, and other automated equipment where precise and reliable linear movement is required.
Product Type:\u200b Hardened & Chrome Plated Linear Shaft Guide Rod
Package Quantity\u200b 2 Pieces per set
Outer Diameter (OD):\u200b 8 mm, 10 mm, 12 mm, 16 mm
Shaft Length (L):\u200b 100 mm to 550 mm (Selectable within this range)
End Configuration:\u200b Threaded hole at both ends
Thread Size (Typical by OD):\u200b 8/10mm OD: M4, M5; 12/16mm OD: M4, M5, M6, M8
Surface Treatment:\u200b Hardened & Chrome Plated
Primary Applicationu200b Linear guide rod for motion systems in 3D printers, CNC machines, automation projects.
