TC4M-14R Digital PID Temperature Controller, 72x72mm, Single Display 4 Digit, Relay Output 3A + 1 Alarm, 100-240VAC 50/60Hz, Universal Input (Thermocouple/RTD) Thermostat

SAR 261
– 1 +

Special Features

  • Precise PID Control: Built-in high accuracy PID chip.It controls the temperature stably via Relay Output, preventing overheating or cooling issues.
  • Simplified Operational Process: Features an intuitive digital interface with clear LED displays for PV (Present Value) and SV (Set Value).Users can easily set target temperatures or adjust parameters without navigating through overly complex menus.
  • Temperature Control Accuracy: Uses a digital microprocessor for signal processing and data display.The controller regulates the output based on sensor feedback to maintain the target temperature within the specified range and minimize fluctuation.
  • Industrial Application: Compatible with automation systems in various sectors.Typical applications include light industry, chemical processing, injection molding machinery, metallurgy, ceramics, and petrochemical equipment.
  • Installation Note: Please strictly verify that your power supply voltage matches the controller specifications before installation.Always disconnect the power before replacing the unit to prevent electrical shock or damage to the device.

Description

Size: DIN W72×H72mm
Display method : 4-digit 7-segment LED
Control method : ON/OFF, P, PI, PD, PID
Input specification : Thermocouple: K(CA), J(IC), L(IC)
RTD: DPt100Ω, Cu50Ω
Sampling cycle : 100ms
Control output : Relay (250VAC~ 3A) or SSR drive (12VDC specialstring) [ON/OFF, phase, cycle]
Power voltage : 100-240VAC~ 50/60Hz
Display accuracy_RTD/Thermocouple:
At room temperature(23ºC ± 5ºC):(PV ± 0.5% or ±1ºC, select the higher one) ± 1-digit
Out of room temperature range:(PV± 0.5% or ±2ºC, select the higher one)± 1-digit
Hysteresis(adjustable sensitivity):
1 to 100℃/℉(0.1 to 50.0℃/℉) variable
Ambient temperature:
-10 to 50℃, storage: -20 to 60℃
Ambient humidity:
35 to 85% RH, storage: 35 to 85% RH
