Plug Valves
Technical Parameters
Material
Nylon plastic body, NBR seal
body fluid
water
Fluid temperature
43℃
ambient temperature
52℃
Use voltage
6-20VDC (self-locking coil can be customized), 24VAC, 24VDC, 110VAC, 220VAC
Pulse Width
20-500mSec
Coil resistance
6
capacitance
4700uF
Coil inductance
12 mh
connect
G (imperial thread)
size
100, 1", 25mm (, G thread)
work pressure
1 inch: 1-10 bar
flow
1": 5 cubic meters/hour
operating mode
Spool lock position, valve open, release position, valve closed.
