Globe Valves
Specification
Medium: Cold/hot water, 60% Ethylene Glycol
Material: Brass
Power Supply: AC220V/DC12V/DC24V
Structure Forms: Three Ways,
Operation Mode: Three Wire Two Ways Control
Power: 6W (Only when the valves open and close)
Running Time: 5-15 Seconds
Nominal Pressure: 1.6MPa
Medium Temperature: 2°~95°
Maximum Differential Pressure: 1.0MPa
Connection Mode: G Internal Thread
Torque:220V 8 N.M, DC12/24V 6 N.M
Package list:1PC* Ball Valve
Notice:
1.Please check the model number of the motor, we will not be responsible for the wrong purchase.
2.Motor color red and gray sent randomly, if you mind the color, please do not shoot.
==========
NC or NO : Normally Closed
Actuator Mode : With Manual And Instruction
Structure : Ball
Media : Water
Material : Brass
Temperature of Media : Normal Temperature
Standard or Nonstandard : Standard
Pressure : Low Pressure
Power Source : AC
