Globe Valves
Specifications:
Valve Type: 2 Way Normally Closed (Valve opens with energized)
Port Size: 1/4" Female Port
Diameter of the outlet of the brass joint: 4/6/8/10/12/14/16MM
Coil Voltage: DC12V/DC24V/AC110V/AC220V
Material:
Body Material: Engineering plastics
Seal Material: NBR (Buna N)
Armature Tube Material: Brass
Plunger & Spring Material Stainless Steel
Working temperature 060
Applying pressure: 0.15~0.8Mpa
Ensure pressure: 1.0Mpa
Working method: Internal leading approach
The selected material for the tower connector: 304 stainless steel
==========
Type : Valves
Model Number : -
Voltage : DC 12/24V,AC 110/220V
Solenoid valve internal thread : 1/4
Tower joint material : 304 stainless steel
