Miniature Cylindrical Connectors
Cable specification:0.15mm 2 ~ 0.2mm 2/26~24AWG
Diameter range:5.5mm ~7mm
Contact diameter×Qty:8
Current rating(A):1.5A
Operating voltage(AC.V.rms):500V
Withstand voltage(AC.V)1min:2500V
Insulation resistance:>500M
Durability:500 mating&unmating cycles
Temperature rating-40°C~80°C
Method of connecting cable:Solder
combustion level:UL94-V0
Temperature rise:20A per contact at 30°C, 25A per contact at 40°C, 30A per contact at 50°C.
Material:
Hardware metalZinc alloy(pearl hard chromium)
Contact pin:Copper alloy(gold-plated)
Spring:Stainless steel
Sealing:Silica gel

==========
Model Number : NE8FDP NE8FDE
Voltage : 24V
Origin : Mainland China
