Sensor Blocks
==========
High-concerned chemical : None
is_customized : Yes
Coil Structure : Toroidal
Model Number : K10A-P3S5
Coil Number : Autotransformer
Phase : SINGLE

Certification : ,UL
Use : Current
Measuring current : AC current
Output current : DC 4-20mA
Through hole : 40mm
Supply voltage : DC +24V
Accuracy : ±1.0%
Linearity error : ±1.0%
Response time : 20mS
Bandwidth : DC-2.0KHZ
Insulation voltage : AC 2.5KV 50Hz 1min
Operating temperature : -10~+70
Storage temperature : -25~+85
