1. Not easy to wear, performance. This gear is a good industrial alternative accessory.
2. Widely used in conveying, hardware, agricultural equipment, printing machinery, mechanical transmission and so on.
3. The contact between the gears is firm to ensure the normal operation of the machine and good carrying capacity.
Specification:
Name: 06B Precision Industrial Drive Sprocket Wheel
Type: Sprocket with Step
Material: 45# Steel
Tooth Surface Treatment: High Frequency Quenching and Tempering of Teeth
Tooth Surface Hardness: HRC40-50
Pitch: 9.525mm
Number of teeth: 16 Teeth
Keyway Bore: 10mm (keyway 3mm),12mm (keyway 4mm),14/15/16/17mm (keyway 5mm),18/19/20/22mm (keyway 6mm),25mm (keyway 8mm)
Application: Used in Various Mechanical Transmission Parts
Features:
1. Sprocket material is high quality 45 steel, teeth high frequency quenching, tempering: HRC40-50.
2. Strong resistance to oxidation, acid, alkali.
Note:
1. Sprocket dimensions (such as bore, total thickness, step outer diameter, etc.) may vary slightly due to batch differences, and specific parameters prevail in kind.
