Vacuum Traps
valve
NC:it will be open when power on and close when power off.
Note: This link solenoid valve is suitable for continuous opening for 24 hours without burning. If the power-on time is less than 1 hour it is recommended to choose a cheap solenoid valve.
Continuous working time is less than 1 hour (transfer link)
Thread specification
Type
PPR pipe diameter
Flow bore
L
H
G3/8"
2W-040-10
15mm
4mm
51mm
87mm
(DN10)
G1/2"
2W-160-15
20mm
16mm
58.5mm
101.5mm
(DN15)
G3/4"
2W-200-20
25mm
20mm
67mm
103mm
(DN20)
G1"
2W-250-25
32mm
25mm
84mm
111mm
(DN25)
G1-1/4"
2W-320-32
40mm
32mm
98.5mm
128.5mm
(DN32)
G1-1/2"
2W-400-40
48mm
40mm
106mm
160mm
(DN40)
G2"
2W-500-50
58mm
50mm
133.5mm
177mm
(DN50)
