5 Set 4 Pin 3.81mm Pitch Panel Mount Screw Terminal Block Connector - Phoenix Type Connector - 8A, 300V, 16-28AWG in Saudi Arabia

5 مجموعة 2 دبوس 3.81 مم لوحة الملعب جبل المسمار محطة كتلة موصل - فينيكس نوع موصل - 8A، 300V، 16-28AWG

SAR 47
مقاس2 دبوس-5 مجموعة
– 1 +

مميزات خاصة

  • Safe Wiring Connection: 4-pole panel Mount screw terminal, rated 300V 8 A. Provides stable and safe electrical connections for various devices.
  • Durable & Flame-Retardant: Made of PA66 high-temperature V0 flame-retardant material. No leakage, no short circuit, long service life.
  • Easy to Use: Loosen the screws, insert the wires, and tighten. Quick disconnect design makes device replacement fast and simple.
  • Strong Contact Design: Anti-vibration structure with tin-plated brass and nickel-plated phosphor bronze contacts for reliable conductivity.
  • Package: 5 Set 4pin (Male Plug+ female socket); Pitch: 3.81mm. Wire: 16–28AWG. Wire Range: 0.1-1.5 mm³; Strip length: 7–8mm. Use M2.5 screws (not included).

وصف

Feature
-Type:Panel Mount Terminal Connectors
-Pin: 4 Pin
-Pitch: 3.81mm
-Gender: male & female
-Contact (Female Socket): Tin Plated Brass
-Contact (Male Plug): Nickel Plated Phosphor Bronze
-Plastic Components: PA66, Flame-Retardant
-Rated Value: 8A 300V
-Wire Range:16-28AWG
-Withstanding Voltage: AC1500V/1Min
-Torque:0.4Nm (3.5lb-In)
-Stripping length:7-8mm
-Temperature range:-113°F ~ + 221°F
-Screw and Push-in connection design
Package:
-5set x 4 Pin 3.81mm Pitch male plug & female socket panel Terminal Block Connector
Notice:It's crucial to select terminal blocks that match the specifications of your project to ensure reliable connections and proper functionality within the circuit.
