【30Amp Circuit Breaker】Protect your traction motor from electrical damage and prevent power surge damage; Voltage: 12-48V DC, compatible with all 12V/24V systems.
【Manual Reset Circuit Breaker】Visible reset lever shows open condition, unique push button reset Can also be used as a kill switch; Button on circuit breaker can act as a master disconnect for circuits.
【Surface Mount Circuit Breaker】No need to replace the internal fuse. You can install it directly on the panel or fireproof wall. Terminal Size: 5/16"-18, mounting hole accept #10 (M5) screw, large clearance around terminal studs accepts up to 1/0 AWG lugs.
【Material】Made of alloy and thermoplastic UL material, with a grade of 94V0, it complies with sae J1625, J1171 and UL1500 standards. It is splash-proof, dust-proof, has strong electrical conductivity and can be safely used in harsh environments.
【Application】Suitable for car audio/video system, boat, trucks, buses, RV's, ATV winches marine and DC sound amplifier system overload protection.
One-Year Warranty.

وصف

Type: switchable/manual reset - trip free
The 60amp automotive circuit breaker is made of alloy and thermoplastic UL material, with a grade of 94V0, it complies with sae J1625, J1171 and UL1500 standards. The design of the manual reset arm and pull rod combines the switch and circuit protection into one. It is splash-proof, dust-proof, has strong electrical conductivity and can be safely used in harsh environments.

Other product specifications:
Max voltage: 48V DC
Interrupt rating: 3000A@30V DC
Interrupt capacity: 5000A @12V, 3000A @ 24V, 1500A @ 42V
Product size:(LxWxH) 3.46 x 2.3 x 1.8 inchs
Material: Nickel plated brass+Thermo-set Polyester
Operating Temperature Rating: -40 °F(-40℃)to 185 °F(85 ℃)
Storage Temperature Rating: -40 °F(-40℃)to 260°F(125℃)

Package List:
1 x 30 amp marine circuit breaker
