UPO1084HD | 80 MHz 4Ch 12-Bit Digital Storage OscilloscopeOverview
The UPO1084HD is a 80 MHz 4-channel 12-bit bench oscilloscope with a 7-inch capacitive touchscreen. It samples at 1.25 GSa/s with 100 Mpts memory depth and captures waveforms at up to 1,000,000 wfms/s using Ultra Phosphor 3.0 display technology. The 12-bit ADC provides 16× greater vertical resolution than conventional 8-bit oscilloscopes — a significant advantage for resolving small signals, measuring power supply ripple, and characterizing precision analog circuits.
RS-232, UART, I²C, SPI, RS-422, RS-485, CAN, LIN, Audio decoding is included standard. No optional protocol licenses are required — all supported protocols are included.
Ultra Phosphor 3.0 with 12-bit resolution×Ultra Phosphor 3.0 with 12-bit resolutionKey Features80 MHz Bandwidth, 4 Channels — 4-channel capture with 1.25 GSa/s sample rate and 12-bit vertical resolution.
100 Mpts Memory Depth — Deep memory for extended signal capture without reducing sample rate.
1,000,000 wfms/s Capture Rate — Ultra Phosphor 3.0 intensity-graded display reveals rare anomalies.
12-Bit ADC Resolution — 16× greater vertical detail than 8-bit instruments for precision analog measurement.
Included Protocol Decoding — RS-232, UART, I²C, SPI, RS-422, RS-485, CAN, LIN, Audio included standard.
56 Automated Measurements — Comprehensive waveform characterization with statistics.
7-inch Capacitive Touchscreen — Multi-gesture navigation for efficient operation.
Built-In Power AnalysisThe UPO1000HD includes power analysis functions — ripple, harmonics, SOA, switching loss, and startup timing — at no additional cost. This makes it practical for power supply characterization and educational demonstration of power electronics concepts without requiring a separate analysis li
