Description：
Ultra slim design with 70mm(4SU) width
Universalinput 85~264VAC(277VAC operational)
DC output voltage adjustable
Protections : Short circuit / Overload / Over voltage
Cooling by free air convection
DlN rail Ts-35/7.5 or 15 mountable
LED indicator for power on
HDR-100 is an economical ultra slim 100W DIN rail power supply series, adapt to be installed on TS-35/7.5or TS-35/15 mounting rails. The body is designed 70mm(4SU) in width, which allows space saving inside thecabinets.
HDR-100 is designed with plastic housing that it can effectively prevent user from electric hazards. Withworking efficiency up to 90%, the entire series can operate at the ambient temperature between30'C and 70'C under air convection.

Applications：Household control system，Building automation，Industrial control system，Factory automation，Electro-mechanical apparatus.
