Sundown Audio SML-12 D4 12 in Shallow Subwoofer 600-Watt RMS / 1200-Watt Peak Dual 4-Ohm DVC, 4.45 in Depth, 10.75 in Cutout, 0.05 cu ft Displacement, 39.9 Hz FS, 2-Piece in Saudi Arabia Sundown Audio SML-12 D4 12 in Shallow Subwoofer 600-Watt RMS / 1200-Watt Peak Dual 4-Ohm DVC, 4.45 in Depth, 10.75 in Cutout, 0.05 cu ft Displacement, 39.9 Hz FS, 2-Piece in Saudi Arabia Sundown Audio SML-12 D4 12 in Shallow Subwoofer 600-Watt RMS / 1200-Watt Peak Dual 4-Ohm DVC, 4.45 in Depth, 10.75 in Cutout, 0.05 cu ft Displacement, 39.9 Hz FS, 2-Piece in Saudi Arabia Sundown Audio SML-12 D4 12 in Shallow Subwoofer 600-Watt RMS / 1200-Watt Peak Dual 4-Ohm DVC, 4.45 in Depth, 10.75 in Cutout, 0.05 cu ft Displacement, 39.9 Hz FS, 2-Piece in Saudi Arabia Sundown Audio SML-12 D4 12 in Shallow Subwoofer 600-Watt RMS / 1200-Watt Peak Dual 4-Ohm DVC, 4.45 in Depth, 10.75 in Cutout, 0.05 cu ft Displacement, 39.9 Hz FS, 2-Piece in Saudi Arabia Sundown Audio SML-12 D4 12 in Shallow Subwoofer 600-Watt RMS / 1200-Watt Peak Dual 4-Ohm DVC, 4.45 in Depth, 10.75 in Cutout, 0.05 cu ft Displacement, 39.9 Hz FS, 2-Piece in Saudi Arabia Sundown Audio SML-12 D4 12 in Shallow Subwoofer 600-Watt RMS / 1200-Watt Peak Dual 4-Ohm DVC, 4.45 in Depth, 10.75 in Cutout, 0.05 cu ft Displacement, 39.9 Hz FS, 2-Piece in Saudi Arabia

Sundown Audio SML-12 D4 12 in Shallow Subwoofer 600-Watt RMS / 1200-Watt Peak Dual 4-Ohm DVC, 4.45 in Depth, 10.75 in Cutout, 0.05 cu ft Displacement, 39.9 Hz FS, 2-Piece

SAR 1,950
Brand
Audiosavings
Category
Car Electronics
Weight
16.3 kg
– 1 +

Special Features

  • Package Includes: (2) Sundown Audio SML-12 D4 12" Shallow Car Subwoofers DVC 4-Ohm, Dual 4-Ohm configuration, 600W RMS / 1200W Peak per sub, total 1200W RMS / 2400W Peak for the pair.
  • Electrical Specifications: RE 6.85 Ohms, FS 39.91 Hz, Sensitivity 86.7 dB @ 1W/1m, Xmax 11mm, BL 22.801 N/A, Mms 186.887 g, Cms 85.771 uM/N, Qts 0.513, Qms 3.035, Qes 0.617.
  • Subwoofer Dimensions: Depth 4.45", Cutout 10.75", Motor Diameter 6.14", Displacement 0.05 cu ft. Optimized for 1.25–1.75 cu ft ported enclosure, 0.75–1.0 cu ft sealed, 4th order: 0.75 cu ft sealed / 2.25 cu ft ported, 15 sq in port, 6" port length.
  • Motor & Coil Construction: 2.5" black aluminum voice coil former, high-temperature 4-layer copper wire, stitched Mini-XL tinsel leads, vented pole piece and multi-vented magnetic gap, dual-magnet design for smooth acoustic response, bolt-through motor design.
  • Build Materials & Enclosure Compatibility: Custom tooled cone, ultra-shallow design for under/behind seat installations, designed for ported, sealed, and 4th order band-pass enclosures, high excursion with precise motor control.

Description

The Sundown Audio SML-12 D4 12" Shallow Subwoofer is a dual 4-Ohm DVC configuration delivering 600W RMS and 1200W Peak per sub, totaling 1200W RMS / 2400W Peak for the pair. This shallow design allows installation under or behind vehicle seats while maintaining excursion and low-frequency output.

Each subwoofer features a 2.5" black aluminum voice coil former with high-temperature 4-layer copper wire, stitched Mini-XL tinsel leads, vented pole piece, and multi-vented magnetic gap. Dual-magnet motor design and bolt-through construction ensure consistent performance and mechanical reliability.

Electrical specifications include RE 6.85 Ohms, FS 39.905 Hz, Sensitivity 86.7 dB @ 1W/1m, Xmax 11mm, BL 22.801 N/A, Mms 186.887 g, Cms 85.771 uM/N, Qts 0.513, Qms 3.035, Qes 0.617. Subwoofer dimensions are depth 4.45", cutout 10.75", motor diameter 6.14", displacement 0.05 cu ft.

Optimized for ported enclosures (1.25–1.75 cu ft, 26–30 sq in port, tuned to 35Hz), sealed (0.75–1.0 cu ft), or 4th order band-pass enclosures (0.75 cu ft sealed / 2.25 cu ft ported, 15 sq in port, 6" port length). This design provides controlled low-frequency response in tight spaces without compromising excursion or thermal management.
